X308 (XJ8) Saloons

Production years: 1997 - 2002

A new engine, new interior, styling changes, all took the next generation XJ into even more refined territory.



The very short production run of the previous XJ models (X-300) came about because they were merely a stop gap until Jaguar had developed its first production V8 engine, the AJ-V8 unit. First encountered in the new XK8 sports car in 1996, it was inevitable that it wouldn’t be long before it was fitted to the XJ saloons (now coded X-308) which happened in 1997.



The very refined V8 engines of 3.2 litre and 4.0 litre capacity produced up to 290bhp and were a snug fit into the XJ body shell. The basic shell structure of the body remained unchanged although some inner panels needed adjustment and to ‘show off’ the new models revised more sculptured bumper bars and a new interior dashboard layout were produced.



The range of models followed the previous cars but no longer with an XJ6, just XJ8, Sport, XJR and of course Daimler, now available in two forms, a normally aspirated 4.0 litre (Daimler Eight) and the supercharged model (Daimler Super V8), and both short and long wheelbase lengths were available. Many simple styling changes took place during the life of the cars and also models changes like the Sovereign changed to the SE and the standard model to Executive. A special edition XJR 100 was produced to commemorate the centenary of Sir William Lyons, the founder of the company.



Production of the X-308 models ceased early in 2002 to make way for another new XJ range of cars.

MODEL SUMMARY

MODEL TYPE

PRODUCTION DATES

ENGINE RANGE:

0 - 60 MPH:

TOP SPEED:

X308 (XJ8) Saloons

1997 - 2002

3.2 Litre

3.2 Litre - 8.1 seconds

3.2 Litre - 140 mph

4.0 Litre

4.0 Litre - 6.9 seconds

4.0 Litre - 150 mph

4.0 Litre supercharged

4.0 Litre supercharged - 5.3 seconds

4.0 Litre supercharged - 155 mph

X308 (XJ8) Technical Specifications

Technical Information

Engine Statistics

3.2 Litre

4.0 Litre

4.0 Litre supercharged

Engine (cc)

3248

3996

3996

Bore and Stroke (mm)

86 x 70

86 x 86

86 x 86

Compression Ratio

10.5:1

10.75:1

9:1

BHP

240

290

370

@RPM

6350

6100

6150

Torque (lb ft)

233

290

387

@RPM

4350

4250

3600

Fuellling

Fuel-injection

Fuel-injection

Fuel-injection

Engine Performance

5.3 Litre pre-HE

5.3 Litre HE

6.0 Litre

Top Speed

153 mph

150 mph

161 mph

0 - 60 mph

6.9 seconds

6.5 seconds

6.6 seconds

Fuel Consumption

12.8 mpg

17.9 mpg

17.6 mpg

model Specifications

5.3 Litre pre-HE

5.3 Litre HE

6.0 Litre

Transmission

GM 3-speed 4-speed (all synchro) limited

4-speed (all synchro) limtied

GM 3-speed auto

Wheel Size (in)

15, alloy

15, alloy

15, alloy

Suspension (Front)

Ind wishbone, coils, anti-drive

Ind wishbone, coils, anti-drive

Ind wishbone, coils, anti-drive

Suspension (Rear)

Ind lower wishbone, upper drivelink, , radius arms, coil springs

Ind lower wishbone, upper drivelink, , radius arms, coil springs

Ind lower wishbone, upper drivelink, , radius arms, coil springs

Brakes

4-wheel disc, rear inboard

4-wheel disc, rear inboard

4-wheel disc, rear inboard

Model Dimensions

5.3 Litre pre-HE

5.3 Litre HE

6.0 Litre

Length (in)

191.75

191.75

189.75

Width (in)

70.5

70.5

70.5

Height (in)

49.6

50.4

48.8

Wheelbase (in)

102

102

102

Front Track (in)

58.5

58.5

58.5

Rear Track (in)

58

58

58

Weight (Cwt)

33.2

35

36.6

OPTIONAL EXTRAS

  • Mud flaps
  • Cruise control (where not fitted as standard)
  • Tailored overmats
  • Headlight power-wash system
  • Premium hi-fi system with CD auto-changer in boot
  • Child’s safety seat
  • Child’s booster cushion
  • First-aid kit for boot area
  • Jaguar warning triangle
  • Headlamp converters
  • Headlamp safety covers
  • Mobile telephone kits
  • Snow chains
  • Luggage net for boot area
  • Witter tow bar kit
  • Cup-holder for forward centre console area
  • Heated windscreen
  • Ultrasonic intrusion security system
  • Additional zip-fastening tool kit
  • Heated front seats (where not fitted)
  • Jaguar ‘growler’ alloy wheel centre badges, various colours
  • Power-folding door mirrors
  • Chrome door mirror surrounds (where not fitted)
  • Bright rear-number plate surround (chrome)
  • Self-dipping rear-view mirror
  • Wood/leather steering wheel (where not fitted)
  • Foglamp protective covers
  • Tailored front seat covers
  • Boot cargo net
  • Boot luggage hooks
  • Luggage retainer clips and/or straps
  • Roof-mounted rack
  • Ski/cycle holders
  • Luggage frame for roof rack
  • Compact, sports or large roof box
  • Various options of fitted luggage for the boot
  • Round alloy gear knob
  • Satellite navigation system (later cars)
  • Reverse park aid (where not fitted)
  • Auxiliary power socket
  • Tracker security system
  • Aspheric door mirrors
  • Lockable boot-mounted security box
  • Xenon headlight units (where not fitted)
  • Air filtration system to air-conditioning
  • Engine block heater
  • Cold climate pack
  • Electric sunroof (where not fitted)
  • Rear window blinds
  • Deflector for sunroof
  • CATS suspension package (where not fitted)
  • Chromed grille surround (where not fitted)
  • Alternative woodwork veneers (according to model)
  • 16in 20-spoke alloy wheels (plastic centre caps)
  • 16in Dimple anthracite infill alloy wheels
  • 16in Dimple alloy wheels (plain)
  • 16in Crown alloy wheels (centre cap covers)
  • 16in Starburst alloy wheels
  • 16in Cosmic five double-spoke alloy wheels
  • 16in Lunar seven-spoke alloy wheels (later models)
  • 16in Eclipse five-spoke alloy wheels (later models)
  • 16in multi-spoke Corona alloy wheels (later models)
  • 17in XJR Sport alloy wheels (exposed wheel nuts)
  • 17in Celtic ten-spoke alloy wheels (later models)
  • 18in Penta five-spoke alloy wheels (later models)
  • 18in seven-flute alloy wheels
  • 18in Asteroid seven-spoke alloy wheels (later standard XJR model)
  •
  • R-Performance Specifics
  • 18in Milan split-rim alloy wheels
  • 18in Winter alloy wheels
  • 19in Montreal alloy wheels (later models)
  • Brembo brakes
